Dry Cooler

Dry Cooler

Dry coolers are primarily used for heat dissipation in water and glycol circuits, with cooling capacities ranging from 27 kW to 770 kW. The units feature both standalone and modular designs and can also be customized upon request. The standard electrical configuration is 3 Ph 380 V 50 Hz; with other configurations available on request.

Request a Quote
Dry Cooler
Dry Cooler
Dry Cooler
Dry Cooler
Dry Cooler
Dry Cooler
Dry Cooler
Standard Configuration
  • Two types of water circuit layouts A. Inlet on one side and outlet on the other
    B. Inlet and outlet on the same side
  • Copper tubes with aluminum fins, designed for a standard working pressure of 10 kg/cm² (10 bar).
  • SPCC cold-rolled steel casing with powder-coated finish, offering high structural strength.
    Independent fan modules allow for easy assembly and maintenance.
Applications
  • Dry coolers are widely used in Industrial air conditioning, industrial process cooling, mechanical and process engineering, heating and power stations, IDC / data centers, etc.
  • They are suitable for a wide range of heat dissipation needs and are ideal for outdoor installation.
Technical Specifications
Model Heat exchanger AC cooling fan Water circuit Net weight
(kg)
HTDC-*** Water
(kW) 		30% Glycol (kW) Operating current (A) Input
power
(kW) 		Air
volume (m³/h) 		Fan No.
x Φ 		Water
flow rate
(m³/h) 		Inlet/outlet
flange size
(mm) 		Water
pressure drop(kPa)
84-4x550 84 79 4.8 2.4 35680 4x550 14.4 2xDN40 108 940
116-6x550 116 110 7.2 3.6 53520 6x550 19.9 2xDN50 111 1080
152-6x550 152 144 7.2 3.6 53520 6x550 26.1 2xDN50 113 1390
163-6x630 163 155 9.6 4.8 74520 6x630 28.0 2xDN50 121 1560
202-6x630 202 192 9.6 4.8 74520 6x630 34.7 2xDN65 116 1690
218-8x630 218 207 12.8 6.4 99360 8x630 37.5 2xDN65 127 1770
256-8x630 256 240 12.8 6.4 99360 8x630 44.1 2xDN65 127 1890
302-8x710 302 283 15.2 7.2 120960 8x710 51.9 2xDN80 126 2130
354-10x710 354 332 19 9.0 151200 10x710 60.9 2xDN80 135 2430
429-10x710 429 403 19 9.0 151200 10x710 73.8 2xDN100 136 2610
448-12x710 448 421 22.8 10.8 181440 12x710 77.1 2xDN100 146 2970
Note:
  • Relative humidity: 40%
  • Atmospheric pressure: 1bar
  • Performance based on: ambient temperature 5°C, water inlet/outlet temperatures 17°C / 12°C, and glycol concentration 30%
